| ENGINE: |
|
Air-cooled two-stroke single
cylinder |
| DISPLACEMENT: |
|
27 cc |
| POWER: |
|
1.4 kW at 7.800 rpm |
| TORQUE: |
|
1.92 Nm at 6.600 rpm |
| CARBURETOR: |
|
Walbro with membrane pump |
| IGNITION: |
|
Contact-less |
| STARTING: |
|
Pull start |
| CLUTCH: |
|
Centrifugal automatic |
| FRAME: |
|
High Tensile steel tubing
(welded) |
| BRAKES: |
front |
disc brake - disc diameter 119 mm (
4,7" ) |
rear |
disc brake - disc diameter 119 mm (
4,7" ) |
| WHEELS: |
front |
light alloy 4" - 51 |
rear |
light alloy 4" - 51, with
freewheel |
| TIRES: |
front |
2. 8 - 4" |
rear |
2. 8 - 4" |
| FUEL: |
|
Petrol 92 or higher Octane + 2-stroke
synthetic oil (50:1) |
| FUEL TANK CAPACITY: |
|
1.3 liter (0,338 US gal.) |
| FUEL CONSUMATION: |
|
1 liter/40 km (0,26 US gal./25
mile) |
| SPEED: |
|
Up to 35 km/h ( 22 MPH ) |
| WEIGHT: |
|
15,1 kg ( 33,2 lb. ) |
| WEIGHT INCL. PACKING: |
|
18,1 kg ( 39,8 lb. ) |
| MAXIMUM LOAD: |
|
90 kg (198 lb.) |
| HANDLEBARS: |
|
Foldable, Duralumin |
| DIMENSIONS: |
length |
1035 mm ( 40,7" ) |
width |
418 mm ( 16,5" ) |
height |
1080 mm ( 42,5" ), ( folded 450mm -
17,7" ) |
| PACKING BOX DIMENSIONS: |
length |
110,0 cm (43,3" ) |
width |
45,0 cm ( 17,7" ) |
height |
48,0 cm ( 18,8"
) |
| |
|
|
|
|
