ENGINE: |
|
Air-cooled two-stroke single cylinder
engine |
DISPLACEMENT: |
|
40 cc |
POWER: |
|
2.5 kW (3.4 Hp) at 8.000 rpm |
TORQUE: |
|
3.5 Nm at 6.400 rpm |
CARBURETOR: |
|
14 mm |
IGNITION: |
|
Contact-less |
STARTING: |
|
Pull start |
CLUTCH: |
|
Centrifugal automatic |
FRAME: |
|
High Tensile steel tubing
(welded) |
BRAKES: |
rear |
disc brake – disc diameter 119 mm
(4,7") |
WHEELS: |
front |
light alloy 4" – 51 |
rear |
light alloy 4" – 95 |
TIRES: |
front |
3,00 – 4" |
rear |
3,00 – 4" |
FUEL: |
|
Petrol 92 or higher Oct. + 2-stroke
synthetic oil (50:1) |
FUEL TANK CAPACITY: |
|
1 liter (0,26 US gal.) |
WEIGHT: |
|
29 kg – 63,8 lb. |
WEIGHT INCL. PACKING: |
|
33 kg (72,6 lb.) |
MAXIMUM LOAD: |
|
95 kg (209 lb.) |
DIMENSIONS: |
length |
1 010 mm (39,7") |
width |
590 mm (23,2") |
height |
630 mm (24,8") |
PACKING BOX DIMENSIONS: |
length |
1 050 mm (41,3") |
width |
620 mm (24,4") |
height |
560 mm (22,04") |
|
|
|
|
|
